Male Thread Pneumatic Air Cylinders ISO Cylinder DSBC-40-50-PPVA-N3 1376658

Name: Male Thread Pneumatic Air Cylinders ISO Cylinder DSBC4050PPVAN3 1376658
Brand: FESTO
Price: 1 USD

Wholesale Male Thread Pneumatic Air Cylinders ISO Cylinder DSBC-40-50-PPVA-N3 1376658 from china suppliers

Brand Name : FESTO

Model Number : DSBC-40-50-PPVA-N3

MOQ : 1pc

Price : EXW USD60-70

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 500 pcs per month

Delivery Time : 10-15 working days

Packaging Details : plastic bag, carton，OPP bag

Brand : FESTO

Part no : 1376658

Type : DSBC-40-50-PPVA-N3

Stroke : 50 mm

Piston diameter : 40 mm

Piston rod thread : M12x1.25

Contact Now

FESTO ISO cylinder DSBC-40-50-PPVA-N3 1376658 Pneumatic Air Cylinders

About product

Stroke:50 mm
Piston diameter:40 mm
Piston rod thread:M12x1.25
Wide range of variants provides high level of flexibility
The variants can be configured according to individual needs using a modular product system

Technical Data

Stroke	50 mm
Piston diameter	40 mm
Piston rod thread	M12x1.25
Cushioning	Pneumatic cushioning, adjustable at both ends
Mounting position	optional
Conforms to standard	ISO 15552
Piston-rod end	Male thread
Design	Piston Piston rod Profile barrel
Position detection	Via proximity switch
Symbol	00991235
Variants	Piston rod at one end
Mode of operation	Double-acting
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Cleanroom class	Class 6 according to ISO 14644-1
Ambient temperature	-20°C-80°C
Cushioning length	19 mm
Basic weight for 0 mm stroke	740 g
Additional weight per 10 mm stroke	37 g
Type of mounting	Either: Via female thread With accessories
Pneumatic connection	G1/4
Note on materials	RoHS-compliant
Material coverDie-cast aluminium, coated	Die-cast aluminium, coated
Material piston seal	TPE-U(PU)
Material pistonWrought aluminium alloy	Wrought aluminium alloy
Material piston rod	High-alloy steel
Material piston rod wiper	TPE-U(PU)
Buffer seal material	TPE-U(PU)
Cushioning piston material	POM
Material cylinder barrel	Smooth-anodised wrought aluminium alloy
Material nut	Galvanised steel
Material bearing	POM
Material collar screws	Galvanised steel

Competitive Advantage

Our product features: Our Services Guarantee:

1) Competitive price 1) Prompt respond (Reply with 24 hours)

2) Good quality 2) Free Samples (Customer pay for the delivery cost)

3) Professional Packaging, 3) Registration support.

4) Produce according to Customers’ instruction 4) Photos/videos are available during production.

5) None delay shipment

5) Loading inspection, and send loading photos before shipment.

There are so many models. Please contact with me!
